Extron DP Pro Plenum Series features active, hybrid optical-copper cables for the ultra-high-speed transmission of DisplayPort 1.4 signals. These cables support video resolutions up to 8K/30 @ 4:4:4, HDR, EDID, HDCP, CEC, and 32 channels of audio. Ultra-thin 0.18" (4.7 mm) diameter, narrow bend radius cable construction provides ease of installation in tight spaces, including plenum air spaces, without compromising performance. The active cables are unidirectional and draw ultra-low power from the connected DisplayPort devices. DP Pro Plenum Series cables are available in lengths from 25 feet to 150 feet (7.6 meters to 45.7 meters).
|Signal type||EDID, HDCP, CEC, and 3.3 V power.|
|Max. video data rate||32.4 Gbps|
|Resolution range||8K/30 verified|
|Connector type||1 male DisplayPort to 1 male DisplayPort|
|Available lengths||25 feet to 150 feet (7.6 meters to 45.7 meters)|
|Country of Origin||USA|
