HDMI 1.4b, HDCP 1.4 compliant Video resolution up to 4K@60Hz 4:4:4, as specified in HDMI 2.0b HDCP 2.3, DP 1.4 and HDBase 3.0 compliant USB 3.2 Gen 1 up to 5Gbps 4x2 seamless switching (single screen) and fast switching (multiview) function Manual switching or auto switching mode Multiple multiview display modes: Auto/Single/PIP/PBP/Triple/Quad/Custom Input: 2x USB-C, 2x HDMI, 1x Analog audio, 1x Dante 2ch Output: 1x HDMI, 1x HDMI + HDBaseT mirrored, 1x Analog audio, 1x Dante 2ch USB-C supports DisplayPort Alternate mode for A/V, USB 3.2, 1G LAN and 60W charging Local USB 3.2 switching and extending USB 2.0 over HDBaseT 3.0 Local USB KVM hotkeys and mouse switching Uncompressed 4K60 4:4:4 over HDBaseT 3.0 up to 132ft/40m via single CAT6A cable Uncompressed 1080P&4K30 over HDBaseT 3.0 up to 230ft/70m via single CAT6A cable Audio embedded and de-embedded Audio DSP for gain, equalizer, volume and delay Dante 2x2 audio input and output CEC/RS-232 control external devices ON/OFF Advanced EDID management Support standard PoE power supply from TX to RX (TX_PSE, RX_PD) Flexible control via front panel buttons, IR remote, RS-232, TCP/IP or Web GUI
